FRAME SET
FRAME
torayca t700 ud, with integrated battery and cable routing, 12×142 tru-axle
FORK
nytro onda carbon fork with forkflap™, tapered head tube
DRIVETRAIN
CRANKSET AND CHAINRINGS
most custom chainrings
REAR DERAILLEUR
Shimano Deore 11s 1X
CASSETTE
Shimano Deore 11s 1X
CHAIN
Shimano Deore 11s 1X
BOTTOM BRACKET
Fazua Bottom Bracked
MOTOR
TQ-HPR50 Drive Unit
BATTERY
360 Wh Integrated Battery
DISPLAY
Integrated and Compatible with Ant+ Bike Computers
BRAKES
FRONT BRAKE DISC
Shimano Deore 2 pistons caliper, 160mm rotor
REAR BRAKE DISC
Shimano Deore 2 pistons caliper, 160mm rotor
COCKPIT
HANDLEBAR
most flat handlebar
STEM
most stem
GRIPS
manopole most comfort
SEAT CLAMP
external seat clamp
LIGHTS
Supernova V1280 E-Bike Front Light
WHEELS AND TIRES
TYRES DISC
Randonneur 40-622 Rigid D Reflective
WHEELSET DISC
Shimano RS
AXLES DISC
Pinarello Axle 12×100 & 12×142, Tool Free Removal
